Unicorn Cartagena

RRP £30,699

Unicorn Cartagena

Berths
4
Axle
Twin
Shipping Length
7.815m / 25′8″
Internal Length
6.379m / 20′11″
Overall Width
2.264m / 7′5″
MTPLM
1725kg
MRO
1566kg more info
Payload
159kg upgrade info
RRP Price
£30,699

All data is calculated using metric weights and measurements. The imperial figures quoted are conversions thereof.

Unicorn Cartagena Features

Key Features

  • NEW vertical front infinity window and moulded surround with integral task lighting and speakers
  • NEW standard ‘Chiswick’ soft furnishings
  • NEW optional ‘Temple’ soft furnishings (cost option)
  • NEW Bailey ‘Light Oak’ furniture finish
  • NEW streamline front corner lockers
  • NEW dual finish ‘Satin Cashmere’ British design overhead curved locker doors with ‘Light Oak’ contrasting stripe
  • NEW front corner wall-mounted soft touch storage pouches
  • NEW conventional sprung cushion construction with knee roll base cushions and back rests, featuring premium quality fabrics
  • NEW branded DAB Radio with USB connection point and Bluetooth capability
  • ALDE touch screen user-friendly control panel with back up battery for uninterrupted programming
  • NEW branded Perspex kitchen splashback with chrome detailing
  • NEW built-in kitchen wine rack
  • Drop down kitchen worktop extension
  • Soft close kitchen drawers with cutlery tray
  • Drop down hob cover worktop
  • Thetford dual fuel hob with electric hotplate and three gas burners
  • NEW 700 watt Dometic microwave oven with non-moving ceramic hot plate
  • NEW Dometic 10-series 153 litre electronic fridge freezer with universal handed door mechanism
  • Large fully lined square shower cubicle with bi-fold partition door and integral lighting
  • NEW Belfast style washroom hand basin with swan neck tap and full decorative splashback
  • NEW backlit washroom mirror
  • Superior foam fixed bed mattress construction
  • NEW wider fixed double beds with full width soft touch headboards
  • Up to four USB sockets in directional spotlights and New wall mounted sockets
  • NEW high security door lock
View full screen gallery

Details

  • Structural interlocking aluminium extrusion framework with no external fixing points and concealed awning channels on both sides
  • Five part fully bonded exterior panel assembly system
  • Upper body panels manufactured using superior bead application laminating technology for a stronger more consistent bond
  • Upper body panels built using a timber free construction, incorporating a composite plastic internal skeleton, a high density polystyrene insulation and a GRP inner wall lining
  • Upper body panels cloaked in a single sheet impact resistant GRP outer skin for extra durability
  • EN-1645 Grade III classification for heating and thermal insulation (cold chamber tested)
  • High performance GRP skinned ‘Polar White’ Alu-Tech bodyshell
  • AL-KO one-piece galvanised steel chassis, braking system and running gear
  • New aerodynamic front profile
  • Aerodynamic & aesthetically enhanced rear bodyshell profile
  • New flush-fit single piece front impact resistant bumper with integral chrome capped grab handles and step up a-frame fairing
  • New flush-fit single piece rear impact resistant bumper with integral light cluster
  • New rear vertical pillar mouldings with integral chrome capped grab handles
  • New ‘Silver’ 15” (single axle models) or 14” (twin-axle models) TUV tested alloy wheels
  • Front corner steadies and heavy duty rear corner steadies
  • New vertical front infinity window and moulded surround with integral task lighting and speakers
  • New two-part pleated blind to vertical infinity window
  • Double glazed polyplastic principal windows with Remis pleated flyscreen and blinds
  • Modern look Bailey branded front window with darker screen print
  • Midi and mini Heki rooflights located throughout the habitation area
  • Hartal GRP skin two-part large aperture exterior door with window, waste bin and dustpan and brush, Hartal pleated full length flyscreen and exterior door drip tray
  • LED awning light with integral water management system
  • New easy access exterior through-boot (model specific)
  • Easy access exterior storage lockers
  • New ‘Unicorn Series 5’ graphics scheme
  • New offside exterior service light
  • Centrally mounted easy-access gas locker for enhanced stability and reduced nose weight
  • New Bailey ‘Light Oak’ furniture finish
  • New dual finish ‘Satin Cashmere’ British design overhead curved locker doors with ‘Light Oak’ contrasting stripe
  • Structural locker dividers with greater load bearing capacity
  • Premium quality chrome finish fixture and fittings
  • New streamline front corner lockers
  • ‘Light Oak’ finish freestanding table with dedicated storage
  • ‘Nebula Silver’ wall mounted table (model specific)
  • Two-drawer front chest with slide out occasional table and soft close drawers with low level storage cupboard
  • Slatted front bed make-up system on easy-glide track
  • Beech slat seat bases with sprung hinged tops for extra comfort and ease of access
  • Angled backrest and seat ventilation boards for enhanced heating efficiency
  • New conventional sprung cushion construction with knee roll base cushions and back rests, featuring premium quality fabrics
  • New standard ‘Chiswick’ soft furnishings with co-ordinating curtain panels, two bolster cushions, two large square and two rectangular scatter cushions
  • New optional ‘Temple’ soft furnishings with co-ordinating curtain panels, two bolster cushions, two large square and two rectangular scatter cushions
  • Integrated curtain pelmet
  • New front corner wall-mounted soft touch storage pouches
  • New ‘Hazelnut’ loose fit drop in carpets
  • Textured finish durable floor vinyl
  • Entrance door mat
  • External satellite connection point
  • Status 570 telescopic directional digital television aerial
  • Up to two TV stations with 230v, 12v and two aerial sockets
  • New up to two TV wall mounts (model specific)
  • New branded DAB Radio with USB connection point and Bluetooth capability
  • New pre-wired for WiFi (retailer fit)
  • Beech slat bed bases with sprung hinged tops for extra comfort and ease of access (model specific)
  • New wider fixed double beds with aluminium frames and gas strut assisted opening mechanism (model specific)
  • New wider fixed single beds with aluminium frames (model specific)
  • Superior foam fixed bed mattress construction (model specific)
  • New full width soft touch fixed bed headboards (model specific)
  • New fold-out pull-up bunk (model specific)
  • New dual shaped wardrobes to maximise fixed bed size, including mattress height storage cubby holes (model specific)
  • New ‘Nebula Silver’ finish kitchen worktop laminate
  • Drop down kitchen worktop extension (model specific)
  • Drop down hob cover worktop in matching ‘Nebula Silver’ finish
  • Stainless steel round kitchen sink with concealed fixings, swan-neck mixer tap, washing up bowl, drainer and chopping board
  • New branded Perspex kitchen splashback with chrome detailing
  • Remis splash proof roller blind to kitchen window
  • Soft close kitchen drawers with cutlery tray
  • New built-in kitchen wine rack
  • Dometic 101 litre refrigerator & 12 litre freezer with high security travel lock (model specific)
  • Dometic 133 litre tower refrigerator & 12 litre freezer with high security travel lock (model specific)
  • Dometic 10-series 153 litre electronic fridge freezer with universal handed door mechanism & high security travel lock (twin axle models only)
  • Thetford ‘K-Series’ combined oven, grill and hob with electronic ignition and flame failure device
  • Thetford duel fuel hob with electronic hot plate and three gas burners
  • New 700 watt Dometic microwave oven with non-moving ceramic hot plate
  • Domestic style washroom door with domestic metal handle
  • New ‘Cashmere’ finish washroom worktop laminate
  • Inboard shower unit with ceramic ball mixer tap and Ecocamel shower head
  • Large white fully lined square shower cubicle with bi-fold partition door and integral lighting (model specific)
  • Large white fully lined square shower cubicle with single piece door and integral lighting (model specific)
  • Ceiling mounted pull down hanging rail on shower hood
  • New in-shower moulded storage
  • New Belfast style washroom hand basin with swan-neck tap and full decorative splashback
  • New backlit washroom mirror (model specific)
  • Built in Thetford C-260 cassette toilet with remote header tank and recessed toilet roll storage shelf (model specific)
  • New Offside 230v power inlet for mains hook-up with integrated aerial jack outlet and Whale Easi-Slide cover
  • Truma 80 watt solar panel
  • Exterior 230v socket with New Whale Easi-Slide cover
  • 12v internal lighting system including LED down-lighters and directional spotlights plus ambient over locker and mid-level feature lighting
  • New curtain track lighting
  • 230v power supply with up to six interior sockets
  • Up to four USB sockets in directional spotlights and New wall mounted sockets
  • New centrally located electrical control panel
  • Centrally located under floor leisure battery storage locker
  • Domestic style consumer unit with dedicated access door
  • Switch mode battery charger with 20 amp output
  • RCD/MCB protection for mains electric system
  • Pre-wired for motor mover (Retailer fit)
  • 25 metre mains connecting lead
  • Alde Hydronic Compact 3020 programmable radiator heating system with combined water heating
    • Alde 3020 boiler for improved fuel economy
    • Dual fuel 6.4kw gas and up to 3.15kw electric power sources
    • Alde touch screen user-friendly control panel with back up battery for uninterrupted programming
    • Washroom panel radiator
  • On-board 40L water tank (twin axle models only)
  • Propane/Butane 30mb gas regulator mounted in gas locker compartment
  • Whale high flow submersible pump
  • Inboard rigid pipe waste plumbing system
  • Truma gas BBQ point with New Whale Easi-Slide cover
  • New high security exterior door lock
  • AL-KO ATC trailer control system
  • AL-KO AKS 3004 stabiliser
  • AL-KO shock absorbers
  • WSL individually laser balanced wheels fitted with ‘Security’ tyres and anti-tamper WSL safety bolts
  • AL-KO chassis mounted spare wheel carrier and steel spare wheel
  • AL-KO caravan jack
  • AL-KO Secure portable wheel lock (two for twin axle models)
  • TRACKER Monitor Thatcham CAT 7 approved Stolen Vehicle Recovery System (including first 3 months subscription fee)
  • TRACKER PIR activated intruder alarm featuring a tilt sensor and key fob operation
  • High security one-key operation throughout
  • CRiS identity number anti-tamper labels attached to windows and inside gas locker
  • Concealed security data chip within caravan construction
  • Smoke alarm
  • Carbon monoxide alarm
  • European Whole Vehicle Type Approved to be European Standard compliant and certified by the National Caravan Council
  • Supplied with a 6-year transferable bodyshell integrity warranty and a 3-year transferable manufacturers warranty
  • 4-year transferable extension to bodyshell integrity warranty (making 10 years in total) and/or 3-year transferable extension to manufacturer’s warranty (making 6 years in total) available as cost options
  • Terms and conditions apply. Please visit baileyofbristol.co.uk/warranties-servicing for more information
  • Truma iNet system (Retailer fit)
  • New optional ‘Temple’ soft furnishings
  • Bespoke caravan bedding sets to co-ordinate with caravan soft furnishings (model specific)
Range
Unicorn
Model
Cartagena
Berths
4
Internal Length
6.379m / 20′11″
Shipping Length
7.815m / 25′8″
Overall Width
2.264m / 7′5″
Overall Height
2.669m / 8′9″
Internal Headroom
1.960m / 6′5″
Awning Size
1076cm
Tyre Sizes
185/65R14
MTPLM
1725kg
MRO
1566kg
Total User Payload
159kg

Bed Sizes:

Front Double
1.93m x 1.52m / 6'4" x 4'11" Measured from the widest point
Front N/S Single
1.95m x 0.63m / 6'5" x 2'1" Measured from the widest point
Front O/S Single
1.95m x 0.63m / 6'5" x 2'1" Measured from the widest point
Rear Fixed Double
1.90m x 1.44m / 6'3" x 4'9" Measured from the widest point

RECOMMENDED RETAIL PRICE £30,699

RRP as at 15th July 2021 (prices include VAT @20%)

Price Guarantee: These prices are guaranteed subject to you ordering your caravan from the earliest production availability and that you take delivery within 14 days of dispatch from the factory.

Retailer Delivery Charge. Your Bailey Retailer will make a charge of up to £565 to cover the cost of various additional services carried out prior to you taking possession of your new Bailey tourer. The main element of this charge will be the cost of transporting your tourer from the Bailey factory to your vending Retailer’s premises. Your Bailey Retailer can confirm the details of the additional services available prior to making your choice.

Optional ExtrasRRPKG
Truma iNet system (Retailer Fit)£199150g
New optional 'Temple' soft furnishings£225Nil
Bespoke caravan bedding sets to co-ordinate with caravan soft furnishings (model specific)£229.99Up to 7.3kg
4-year extension to standard 6-year bodyshell integrity warranty (ten years in total)* inc IPT £265Nil
3-year extension to standard 3-year manufacturers warranty (six years in total)* inc IPT£439Nil
