Unicorn Madrid Series 3

2014 - 2017

Unicorn Madrid

Berths
3
Axle
Single
Shipping Length
7.372m / 24′2″
Internal Length
5.830m / 19′2″
Overall Width
2.28m / 7′6″
MTPLM
1496kg
MRO
1352kg more info
Payload
144kg

All data is calculated using metric weights and measurements. The imperial figures quoted are conversions thereof.

Please remember this is a pre-owned model and will not necessarily be in stock at your local Approved Bailey Retailer. Please contact them before planning visit to confirm which pre-owned models they currently have available for sale.

Key Features

  • 'Polar White' GRP bodyshell
  • Opening vertical skylight
  • AL-KO AKS 3004 stabiliser
  • TUV 14" tested alloy wheels
  • Exterior 230v socket
  • Premium branded tyres
  • AL-KO shock absorbers
  • TyrePal pressure monitor system ready
  • AL-KO ATC trailer control system
  • TRACKER retrieve system
  • AL-KO Secure portable wheel lock
  • AL-KO caravan jack
  • 100 watt Truma solar panel
  • External Truma gas BBQ point
  • Alde programmable radiator heating and hot water system
  • External satellite connection point
  • Branded Radio/CD/MP3 player with iPod/MP3 connection point
  • Dometic 133 litre refrigerator (single axles only) or Dometic 190 litre fridge and freezer (twin axles only)
  • Thetford dual fuel hob with 3 gas burners and electric plate
  • Thetford Caprice combined oven and separate grill

Details

  • Structural interlocking aluminium extrusion framework with no external fixing points and concealed awning channels on both sides
  • Five part fully bonded exterior panel assembly system
  • Upper body panels manufactured using superior bead application laminating technology for a stronger more consistent bond
  • Upper body panels built using a timber free construction, incorporating a composite plastic internal skeleton, a high density polystyrene insulation and a GRP inner wall lining
  • Upper body panels cloaked in a single sheet impact resistant GRP outer skin for extra durability
  • EN-1645 Grade III classification for heating and thermal insulation (cold chamber tested)
  • European Whole Vehicle Type Approved and certified by the National Caravan Council to be European Standard compliant
  • ‘Polar white’ bodyshell
  • Aero-dynamic and aesthetically enhanced rear bodyshell profile
  • AL-KO one-piece galvanised steel chassis, braking system and running gear
  • Flush-fit rear impact resistant bumper with integral chrome grab handles
  • Design step up a-frame fairing
  • 14” TUV tested alloy wheels
  • Heavy duty rear corner steadies
  • Hartal GRP skin two-part large aperture exterior door with window, blind and waste bin
  • LED awning light with integral water management system
  • Double glazed Polyplastic opening vertical skylight in front dome
  • Double glazed Polyplastic opening windows throughout
  • Midi and mini Heki roof lights located throughout the main habitation area
  • Centrally mounted easy-access gas locker for enhanced stability and reduced nose weight
  • Exterior 230v socket and Truma gas BBQ point
  • 230v power inlet for mains hook-up
  • Status 550 telescopic directional digital television aerial
  • External satellite connection point
  • Centrally located easy-access large exterior storage locker with moulded liner
  • Co-ordinating graphics scheme
  • Internal headroom of 1.96m (6’5’’) throughout the length of the caravan
  • Body width of 2.28m (7’6”)
  • Internal floor space up to 15% larger**
  • Front seats up to 10% longer**
  • Kitchen worktop space up to 10% larger**
  • **Size comparison with equivalent models in the previous Unicorn range
  • Bailey ‘Mendip Ash’ furniture finish
  • Large front window shelf with heating vents
  • Recessed 2-drawer front chest with slide out occasional table and soft close drawers
  • Twin concealed storage pockets
  • Double skin bed box frames with beech sprung tops and drop down flaps
  • Slatted front bed make-up system on easy-glide track
  • Leatherette skylight surround with integral ambient and task lighting
  • Angled backrest and seat ventilation boards for enhanced heating efficiency
  • Lightweight freestanding table with dedicated storage
  • Vented aircraft style overhead locker system with split level storage and domestic soft close metal hinges
  • Structural locker dividers with greater load bearing capacity
  • Dual finish Italian design overhead locker doors
  • Dual-position slide-out TV bracket (model specific – accommodates a TV up to 18.5” in size)
  • Premium quality chrome finish fixtures and fittings
  • Internal grab handle for ease of access in and out of the caravan (model specific)
  • Leatherette multi-functional storage pouch
  • ‘Italian stone’ finish kitchen and washroom worktop laminate
  • Drop-down kitchen worktop extension
  • Co-ordinating Perspex splash-back
  • Fixed double beds with aluminium frames and gas strut assisted opening mechanism
  • Solid domestic style washroom door with domestic metal handle
  • Fitted linen basket in washroom
  • Upholstery featuring premium quality fabrics, high density filling and superior ‘Honeycore’ foam construction
  • Standard ‘Kensington’ soft furnishings with co-ordinating curtains, four shaped arm rests, two large square and two small rectangular scatter cushions
  • Optional ‘Trafalgar’ soft furnishings with co-ordinating curtains, four shaped arm rests, two large square and two small rectangular scatter cushions
  • Textured finish durable floor vinyl
  • Deep pile loose fit drop in carpets (55oz pile weight)
  • Truma 100 watt solar panel
  • 230v power supply with up to seven new design interior sockets
  • TV station with 230v, 12v and two aerial sockets
  • 12v internal lighting system including LED down-lighters and directional spotlights
  • 12v shower cubicle lighting
  • Centrally located under floor leisure battery storage locker
  • Centrally located electrical control panel
  • Domestic style consumer unit with dedicated access door
  • Switch mode battery charger with 20 amp output
  • RCD/MCB protection for mains electric system
  • 25 metre mains connecting lead
  • Alde Hydronic Compact 3020 programmable radiator heating system with combined water heating
  • Alde 3020 boiler for improved fuel economy
  • Alde touch screen user-friendly control panel
  • Washroom panel radiator
  • Dual fuel 6.4kw gas and up to 3.15kw electric power sources
  • Propane/Butane 30mb gas regulator mounted in gas locker compartment
  • On-board 40L water tank (twin axles only)
  • Whale high flow submersible pump
  • Inboard rigid pipe waste plumbing system
  • Stainless steel circular kitchen sink with swan-neck mixer tap, washing up bowl, drainer and chopping board
  • Thetford C-260 cassette toilet with integrated header tank
  • Inboard shower unit with ceramic ball mixer tap and Ecocamel shower head
  • Large fully lined square shower cubicle with domestic style door and storage shelf
  • Extendable shaving mirror in washroom
  • AL-KO ATC trailer control system
  • AL-KO AKS 3004 stabiliser
  • AL-KO shock absorbers
  • WSL individually laser balanced wheels fitted with premium brand tyres and anti-tamper WSL safety bolts
  • NEW TyrePal Tyre Pressure Monitor System (TPMS)
  • Wind down floor mounted spare wheel carrier and spare wheel (steel spare wheel)
  • AL-KO caravan jack
  • AL-KO Secure portable wheel lock (two for twin axle models)
  • TRACKER Retrieve with 5-year standby battery life (including first 3 months subscription fee)
  • High security one-key operation throughout
  • CRiS identity number anti-tamper labels attached to windows and inside gas locker
  • Concealed security data chip within caravan construction
  • Smoke alarm
  • Carbon monoxide alarm
  • Exclusive Dometic 133 litre tower refrigerator with electronic ignition (single axles only)
  • Dometic 190 litre fridge and freezer with electronic ignition (twin axles only)
  • Thetford Caprice combined oven, grill and hob with electronic ignition and flame failure device
  • Thetford dual fuel hob with electric hotplate and 3 gas burners
  • Stainless steel 800 watt microwave oven
  • Remis pleated flyscreen and blinds to principal windows
  • Remis 2-part pleated flyscreen and blind to vertical skylight
  • Hartal pleated full length flyscreen to exterior door
  • Branded DAB Radio/CD/MP3 player with iPod/MP3 player USB connection point
  • Branded dual cone stereo speakers for superior sound quality
  • Caravan clock
  • ‘Trafalgar’ soft furnishings
  • Bespoke caravan bedding sets to co-ordinate with caravan soft furnishings (model specific)
Year last produced
2017
Range
Unicorn
Model
Madrid
Series
Series 3
Berths
3
Internal Length
5.830m / 19′2″
Shipping Length
7.372m / 24′2″
Overall Width
2.28m / 7′6″
Overall Height
2.61m / 8′7″
Internal Headroom
1.96m / 6′5″
Awning Size
1045cm
Tyre Sizes
185/R14C LI102R
MTPLM
1496kg
MRO
1352kg
Total User Payload
144kg

Bed Sizes:

Front Double
6’2” x 6’6” Measured from the widest point
Front N/S Single
6’2” x 2’2” Measured from the widest point
Front O/S Single
6’4” x 2’2” Measured from the widest point
N/S Single
6’4” x 2’4” Measured from the widest point
